AB1530RJ Plus

PRODUCT

HIGHLIGHTS

 Precision Performance

• Largest articulating boom in the industry with a maximum platform working height of 159ft and over 83ft of horizontal outreach
• Industry leading 53ft below ground coverage
• Industry leading 63ft of up and over clearance
• Ideal for outdoor construction and industrial applications
• Delivers access to up, over, and out applications, where traditional telescopic booms could not access
• Fully proportional joysticks provide safe and controlled operation to all jobsite applications
• 4WD/4WS allows operator to position the boom in even the hardest to reach areas

 Intelligent Maintenance

• Industry leading 7″ color screen displays standard and Deutz fault codes, and status information, for easy reference, reducing down-time. Operators can complete tasks under the
  remote guidance of qualified service technicians. Convenient for fleet managers to quickly access live machine and maintenance information

Extra Platform Capacity

• Industry leading platform capacity of 1,000lbs in the articulating boom category

Operating Efficiency

• The platform can be raised and lowered to any position without the need to operate the secondary boom

DIMENSIONS

Max Working Height

158’11”

Length-Stowed

49’3″

Wheelbase

17’1″

Max Platform Height

152’11”

Width-Stowed

8’2″

Ground Clearance

.1’1″

PERFORMANCE

Platform Capacity (Restricted/Unrestricted)

1,001 lbs/606 lbs

Platform Rotation Angle

180 degrees

Gradeability

40%

Turntable Tailswing

15’1″

Platform Occupants (Restricted/Unrestricted)

3 persons/2 persons

Drive Speed-Stowed

2.8mph

Turning Radius (Inside)

23’4″

Tilt Rating

5°

POWER

Drive x Steering

4WD x 4WS

Engine

74.4 kW/2300rpm/TCD3.6 L4 T4f/Deutz

System Voltage

12V DC

Weight

60,186 lb
