4389RE

PRODUCT

HIGHLIGHTS

Outstanding Performance

• Electric-powered rough terrain scissor lift, capable up to 50% gradeability, delivering superior performance on sloped and uneven surface
• High platform capacity enables exceptional operational efficiency, supporting demanding job site requirements
• Dual-direction extendable platform provides a spacious and versatile working area for increased productivity
• Large torque from the electric motor ensures smooth climbing with 50% gradeability

 Easy Maintenance

• Onboard fault diagnostics with integrated error codes and resolution guidance

Environment-friendly

• Meets indoor emission requirements and no loud noise generated

DIMENSIONS

Max Working Height

48’7″

[C] Length-Stowed

16′

[E] Height-Stowed Rail Unfolded

9’9.3″

Ground Clearance

1’2.2″

[A] Max Platform Height

42’11.7″

[D] Width-Stowed

7’5.7″

Height-Stowed Fixed Rail

–

PERFORMANCE

Platform Allowable Occupants (Indoor/Outdoor)

7 Persons

Drive Speed-Stowed

3.3mph

Descent Time (Unloaded)

34s~44s

Tilt Rating (Front to Back/Side to Side)

2°/0.8°

Platform Capacity

1,499 lb

Drive Speed-Raised

0.68mph

Gradeability

50%

Tires-solid

33×12-20

POWER

Batteries

48 V,480 Ah

System Voltage

12V DC

Weight (Indoor/Outdoors)

18,739 lb

Floor Loading (maximum ground pressure)

–
