TB1370RJ Plus
Telescopic Boom Lift
Working Height
142’6″
Platform Capacity (Restricted/Unrestricted)
1058 lb/
749 lb
PRODUCT
HIGHLIGHTS
Superior Platform Height
- Highest platform height in the industry
Superior Outreach
- Best horizontal outreach in its class
Rotating Jib
- 235° rotating jib
Intelligent Maintenance
- Industry-leading 7″ color screen displays standard with Deutz fault codes and status information for easy reference, and reducing downtime. Operators can complete tasks under the remote guidance of qualified service technicians. Convenient for fleet managers to quickly access live machine and maintenance information
Highest Platform Capacity
- Industry-leading platform capacity of 1,058 lb (480 kg)
- Platform capacity for 3 persons
DIMENSIONS
Max Working Height
142’6″
[A] Length-Stowed
50′
[D] Wheelbase
14’5″
Max Platform Height
136’6″
[B] Width
8’2″
Ground Clearance
1’7″
Max Horizontal Extension (Unrestricted/Restricted)
81’/ 77’5″
[C] Height-Stowed
9’4″
Platform Dimensions (LxWxH)
8′ x 3′ x 3’7″
PERFORMANCE
Platform Capacity (Unrestricted)
749lb
Platform Rotation Angle
160 degrees
Gradeability
40%
Turntable Tailswing
(Axels Extended/Retracted)
5’6″ / 7’7″
Platform Capacity (Restricted)
1058 lb
Drive Speed-Stowed
3mph (4WD)
Turning Radius (Inside)
6’2″
Tilt Rating
5°
Turntable Rotation
360 degrees/continuous
Drive Speed-Raised
0.68mph
Turning Radius (Outside)
17’2″
Tires Spec/Type
445/50D710 18PR (foam-filled)
POWER
Drive x Steering
4WDx2WS
Fuel Tak Capacity- Diesel
44 gal
System Voltage
12V DC
Engine
54 kW/2400 rpm/QSF2.8t3TC72/Cummins/China T3
Hydraulic Tank Capacity
61.6 gal
Batteries
Weight
49,383 lb
Floor Loading (maximum ground pressure)
–
Standards Compliance
ANSI/CSA
STANDARD FEATURES
- Full-time oscillating front axle
- Fully proportional joystick controls
- Automatic Platform Leveling
- Tilt protection system
- Flashing beacon
- Rotating jib
- Manual storage box
- 7″ Color display screen
- Hydraulic cylinder protective covers
- Automatic platform leveling
- Horn & buzzer
- 8′ (2.44m) platform
- Secondary guarding device
- AC power to the platform
- 4WDx2WS
- Weighing system
- Emergency stop system
- Emergency lowering system
- Fault diagnosis system
- Foam-filled tires
OPTIONAL FEATURES
- Foam-filled non-marking tires
- 6′(1.83m) work platform
- Glazier kit (For platform with swinging gate)
- Solid tires
- 6′ (1.83m)/8′ (2.44m) platform with swinging gate
- Half mesh (For platform with swinging gate)
- Telematics
- Platform work lights
- Overhead anti-collision device
