VM120E
Vertical Mast Lift
Working Height (Indoor Only)
25′
Platform Height (Indoor Only)
19′
PRODUCT
HIGHLIGHTS
Outstanding Performance
- Maintains a 500 lbs platform capacity, supporting a wide range of tools and personnel
- Lightweight and compact footprint meets tight jobsite access requirements
- Front wheel drive offers a small turning radius
Easy Operation
- Saloon-style entry gate enables quick and convenient access to the platform
- Mast is almost the same height as the guardrails for easy and comfortable operation on the platform
Low Maintenance Cost
- AGM maintenance-free batteries come as standard, decreasing total cost of ownership
- Unique bumper rail design helps protect paint and keeps the machine like new
DIMENSIONS
Max Working Height
25′
Length-Stowed
4’6.3″
Ground Clearance (Pothole Guard Stowed)
2.7″
Max Platform Height
19′
Overall Width
2’6.7″
Ground Clearance (Pothole Guard Deployed)
0.59″
Height-Stowed
5’5.4″
Wheelbase
3’5.7″
Platform Dimensions (LxWxH)
4’5″ x 2’6″ x 3’8″
PERFORMANCE
Platform Allowable Occupants (Indoor/Outdoor)
2 Persons
Drive Speed-Stowed
2.5mph
Platform Capacity
500lbs
Drive Speed-Raised
0.3mph
Tires-solid
12×4″
Turning Radius (Inside/Outside)
5.5″/4’5″
Gradeability
25%
Max Allowable Inclination (Front-To-Back/Side-To-Side)
3°/1.5°
POWER
Batteries
24V,120AH
Charger Input
100～240 V AC/15 A
Weight (Indoor/Outdoors)
1,720lbs
Power Source
24V DC /2.2 kW
Charger Output
Drive Mode
2 WD×2 WS
Hydraulic System Capacity
1.3 gal (UK)/1.6 gal (US) (6L)
STANDARD FEATURES
- 2WD x 2WS
- Non-marking tires
- Emergency stop
- Flashing beacon
- Horn and buzzer
- Weighing system
- Maintenance-free battery
- Automatic braking system
- Fault diagnosis system
- Lifting eyes
- Automatic pothole guard system
- Bumper rails
- Fully proportional controls
- Emergency lowering system
- Zero inside turning radius
- Electrophoretic painting
- Drivable at full height
- Telematics (Optional)
